Make Air More Fresh
And Nutritious

"Smart-Clean" Series

Fresh Air Heat Exchanger

  Professional Blower Made In Germany   Multi-function Purpose  Long Service Life
  All-aluminum Heat Exchanger Core   Low Energy Consumption  Consumable-free Replacement
 Simple Installation And Maintenance   High Air Supply Static Pressure  High Heat Recovery Efficiency

  • Reduce Energy Loss

    Consist Of Heat Recovery Units And Pipelines,
    Recycle Energy Loss In Outdoor Exhaust While
    Sending Clean Fresh Air Into The Room;

  • Consumable-free Replacement

    Adopt Full-aluminum Exchange Of Core, Put An End
    To The Loss Of Traditional Paper Filter Which Need
    To Be Replaced Periodically, Raise The Efficiency
    Of Energy Recovery And Reduce
    Energy Costs At The Same Time;

  • Professional Blower Made In Germany

    Ebm Blower Made In Germany Which Has Features Of
    Large Air Volume, High Wind Pressure, Low Vibration,
    Low Noise, Low Consumption And Maintenance-free Etc.,
    And It Can Reduce Operation And Maintenance Costs
    Of All- Heat Exchanger; The Energy-conservation
    And High Efficient Motor Avoids The Problems Of
    Small Air Supply Pressure And Low Air Amount
    Of Conventional Fresh Air System;

  • Multi-function Purpose

    Blower Can Be Controlled And Operated Independently,
    And The Units Can Be Used As A Heat Recovery Units
    Independently, And Also Can Be Used As Exhaust
    Units Independently ; When Atmospheric Pollution
    Is Out Of Limits, Bypass Mode Can Be Used
    To Cut Off The Outside Pollution;

  • Long Service Life

    OAXISI Heat Recovery Units Series Use Zinc- Aluminum
    Alloy Panel With Inner Leak-proof Lining
    And Noise Reduction Sponge, Which Can Be Used
    For Long-term With Guaranteed Strength And
    Is Not Easy To Be Corroded; The Overall Air
    Leakage Rate Of The Device Is Less Than 1% ;

  • Auxiliary Electric Heating Mode

    When Used In The North China Market, When
    The Outdoor Temperature In Winter Is Below 4 ℃ ,
    Auxiliary Electrical Heating Starts Automatically
    To Avoid The Influence Of Low Outdoor Temperature
    On The Room Temperature.

Model Air
Volume
（m3/h）		 Heat Recovery
(%)		 External
Excess
Pressure
（pa）		 Purification
Efficiency		 rated
voltage
(V)		 Power
(W)		 Noise
（dBA）		 Tuyere size
（mm)		 Take Over
Dimension
（mm)		 Weight
（KG)
Height Middle Low Height Middle Low Height Middle Low Long Breadth Height
AR-1 250 200 170 60 93 67 85 ＞99% 220V-50Hz 95 40 37 34 955 640 220 Φ150 28
AR-2 350 280 240 60 63 67 90 ＞99% 220V-50Hz 160 43 40 36 960 702 260 Φ150 32
AR-3 500 380 260 64 66 69 90 ＞99% 220V-50Hz 170 48 45 42 1130 1106 312 Φ200 45
Note: 1. The Above Models Include Initial Filter And Efficient Filtration.
2. The Cross-flow Of Ar-1 And Ar-2 Models And The Parallel Two-way Flow Of Ar-3 Models.
